Fender 5e3 Schematic. Fender Tweed Deluxe 5e3 Schematic Many would say the Deluxe reaches a pinnacle of design with the 5E3, becoming the ultimate tone machine for public performance and recording 5e3 Tube layout (Seen from behind, V1 is to the right side) V1 12aY7 = Preamp normal and bright channel; V2 12aX7 = Preamp normal and bright channel; V3 6V6 = Power tube #1; V4 6V6 = Power tube #2; V5 5Y3GT = Rectifier tube; Summary
Fender Deluxe 5e3 Schematic from guidediagrammarco.z19.web.core.windows.net
A split power amp/preamp ground bus design is used Fender_deluxe_5e3a_layout.pdf - 151 Kb 177: Fender_deluxe_5e3_schem.pdf - 104 Kb 178: Fender_deluxe_6g3.pdf - 174 Kb 179:
Fender Deluxe 5e3 Schematic
Click the image to view the full size (readable) annotated layout FENDER TWEED DELUXE (5E3) Schematic redrawn by Steve Luckey on May 20, 2006 The layout describes the physical arrangement of the pieces and wires, but the schematic is what really tells you what they're doing.
Build an Amp. These are invaluable reference tools if you are digging around inside of your vintage Fender amplifier / -400 DELUXE" SCHEMATIC MODEL 5E3 lg57 Tweed Delu EXTRA Signal aut To speaker voltage High current AC 18 34 8+ High DC 400 AC SWITCH 2 AMP
Fender Tweed Deluxe 5e3 Schematic. The layout describes the physical arrangement of the pieces and wires, but the schematic is what really tells you what they're doing. FENDER TWEED DELUXE (5E3) Schematic redrawn by Steve Luckey on May 20, 2006
